The Minette pump is the next smallest model in the drainage range, but it shares all important features and benefits with the larger models, resulting in the lowest cost per cubic meter pumped. The drainage range of pumps drain water, not your wallet! The revolutionary hydraulic design ensures high wear resistence and dramatically reduces performance drop due to long time wear.
| Technical specifications Pump type: | Electrical submersible One-phase and Three-phase |
| Classification: | IP 68 |
| Max submersion: | 20 meters |
| Cable: | 20 meters, SUBCAB: 1-phase: 3G1.5mm2 3-phase: 4G1.5mm2 |
| Discharge connection: | Hose, ISO-G or NPT |
| Limitations: | pH 5-8 |
| Max liquid temp: | 40°C |
| 50 Hz | 1-ph | 3-ph |
| Discharge connection | 3″ (DN150) | 3″ (DN100) |
| Rated power P2 [kW] | 1,5 | 2,2 |
| Max. power consumption P1 [kW] | 1,9 | 2,7 |
| Shaft speed [r.p.m.] | 2830 | 2800 |
| Rated current at 230V | 8,4 A | 8,1 A |
| Rated current at 400V | – | 4,5 A |
| Rated current at 500V | – | 3,6 A |
| Solids passage [mm] | 9 | 9 |
| Height [mm] | 676 | 676 |
| Diameter [mm] | 240 | 240 |
| Weight [kg] | 29 | 29 |
