Bravo 300

Product code 8147.020; Submersible slurry pumps for pumping fluids with abrasive solids.
All slurry applications don’t require heavy duty pumps, and to meet this demand Grindex offer two smaller models, Bravo 200 and Bravo 300. They are intended for applications with lower demands on capability and wear resistance, and they are not equipped with agitator. For capacities below these, we recommend Grindex sludge pumps. Also available in Explosion Proof version.

Technical specifications Pump type: Electrical submersible three-phase Slurry pump
Classification: IP 68
Max submersion: 20m/66 ft
Cable: 20 m/66 ft SUBCAB [This pump requires an external starter box]
Discharge connection: Hose, BSP or NPT
Limitations: pH 5.5-14
Max liquid temp: 40°C/104°F (70°C/158°F on request)



Specifications 50 HZ 60 HZ
Discharge connection 4″ 4″
Rated power P2 [KW] 5.9 7.5
Max. power consumption P1 [KW] 7.1 8.9
Shaft speed [r.p.m.] 1450 1735
Rated current at 230V 21 A 25 A
Rated current 2 12 A/400V 13 A/460V
Rated current 3 9.5 A /500V 10 A /575V
Solids passage [mm] 50 50
Height [mm] 760 760
Diameter [mm] 460 460
Weight [kg] 157 157
