Product code 8148.020;
Submersible slurry pumps for pumping fluids with abrasive solids.
The Bravo 400 is extremely wear-resistant thanks to the use of Hard-iron™ and the low shaft speed. Equipped with an agitator to enhance the ‘up-stirring’ capabilities it is a superior quality pump for all kinds of slurry applications. Also available in Explosion Proof version.
| Technical specifications Pump type: | Electrical submersible Slurry pump |
| Classification: | IP 68 |
| Max submersion: | 20m/66 ft |
| Cable: | 20 m/66 ft SUBCAB [This pump requires an external starter box] |
| Discharge connection: | Victaulic |
| Limitations: | pH 5.5-14 |
| Max liquid temp: | 40°C/104°F (70°C/158°F on request) |
40°C/104°F (70°C/158°F on request)
| Specifications | 50 HZ | 60 HZ |
| Discharge connection | 4″ | 4″ |
| Rated power P2 [KW] | 13.5 | 15 |
| Max. power consumption P1 [KW] | 16 | 17 |
| Shaft speed [r.p.m.] | 1455 | 1755 |
| Rated current at 230V | 47 A | 52 A |
| Rated current 2 | 28 A/400V | 26 A/460V |
| Rated current 3 | 21 A/500V | 21 A/575V |
| Solids passage [mm] | 30 | 30 |
| Height [mm] | 1148 | 1148 |
| Diameter [mm] | 595 | 595 |
| Weight [kg] | 231 | 231 |
