Product code 8149.020;
Submersible slurry pumps for pumping fluids with abrasive solids.
The Bravo 500 is extremely wear-resistant thanks to the use of Hard-ironTM and the low shaft speed. Equipped with an agitator to enhance the ‘up-stirring’ capabilities it is a superior quality pump for all kinds of slurry applications. Also available in Explosion Proof version.
| Technical specifications Pump type: | Electrical submersible Slurry pump |
| Classification: | IP 68 |
| Max submersion: | 20m/66 ft |
| Cable: | 20 m/66 ft SUBCAB [This pump requires an external starter box] |
| Discharge connection: | Victaulic |
| Limitations: | pH 5.5-14 |
| Max liquid temp: | 40°C/104°F (70°C/158°F on request) |
40°C/104°F (70°C/158°F on request)
| Specifications | 50 HZ | 60 HZ |
| Discharge connection | 4″ | 4″ |
| Rated power P2 [KW] | 18 | 22 |
| Max. power consumption P1 [KW] | 21 | 25 |
| Shaft speed [r.p.m.] | 1460 | 1755 |
| Rated current at 230V | 62 A | 75 A |
| Rated current 2 | 36 A/400V | 38 A/460V |
| Rated current 3 | 29 A/500V | 29 A/575V |
| Solids passage [mm] with agitator | 40 | 40 |
| Height [mm] | 1273 | 1273 |
| Diameter [mm] | 595 | 595 |
| Weight [kg] | 293 | 293 |
