Bravo 600

Product code 8150.020;
Submersible slurry pumps for pumping fluids with abrasive solids.

The Bravo 600 is extremely wear-resistant thanks to the use of Hard-ironTM and the low shaft speed. It can be equipped with an agitator as an option to enhance the ‘up-stirring’ capabilities, but even without the agitator it is a superior quality pump for all kinds of slurry applications. Also available in Explosion Proof version.

Technical specifications Pump type: Electrical submersible Slurry pump
Classification: IP 68
Max submersion: 20m/66 ft
Cable: 20 m/66 ft SUBCAB [This pump requires an external starter box]
Discharge connection: Victaulic
Limitations: pH 5.5-14
Max liquid temp: 40°C/104°F (70°C/158°F on request)



Specifications 50 HZ 60 HZ
Discharge connection 4″ 4″
Rated power P2 [KW] 22 25
Max. power consumption P1 [KW] 25 28
Shaft speed [r.p.m.] 1460 1760
Rated current at 230V 73 A 81 A
Rated current 2 41 A/400V 40 A/460V
Rated current 3 33 A/500V 32 A/575V
Solids passage [mm] with agitator 40 40
Height [mm] 1273 1273
Diameter [mm] 595 595
Weight [kg] 293 293
