The Micro pump excels in applications where reliability and easy handling are essential. It is built to handle contaminated water, pH 5-8, and water containing relatively abrasive solids up to the size of 5 mm.
| Technical specifications Pump type: | Electrical Submersible One-phase |
| Classification: | IP 68 |
| Max submersion: | 10 m |
| Cable: | 10 m, 3x1mm2 |
| Discharge connection: | Hose, BSP or NPSM |
| Limitations: | pH 5-8 |
| Max liquid temp: | 40°C |
| Specifications | 50HZ |
| Discharge connection | 2″ |
| Rated power P2 [kW] | 420 |
| Max. power consumption P1 [kW] | 590 |
| Shaft speed [r.p.m.] | 2760 |
| Rated current at 115V | 5.1 A |
| Rated current at 230V | 2.7 A |
| Solids passage [mm] | 11 x 5 |
| Height [mm] | 440 |
| Diameter [mm] | 185 |
| Weight [kg] | 12 |
