Product code 8122.211;
The Mini pump excels in applications where reliability and easy handling are essential. It is built to handle contaminated water, pH 5-8, and water containing relatively abrasive solids up to the size of 5 mm.
| Technical specifications Pump type: | Electrical submersible One-phase |
| Classification: | IP 68 |
| Max submersion: | 10 m |
| Cable: | 10 m, H07RN-F, 3x1mm2 |
| Discharge connection: | Hose, BSP or NPSM |
| Limitations: | pH 5-8 |
| Max liquid temp: | 40°C |
| Specifications | 50HZ | 60HZ |
| Discharge connection | 2″ | 2″ |
| Rated power P2 [kW/W] | 900 | 0.45 |
| Max. power consumption P1 [kW/W] | 1200 | 0.65 |
| Shaft speed [r.p.m.] | 2800 | 3300 |
| Rated current at 115V | 11 A | 5.5 A |
| Rated current at 230V | 5.2 A | 2.9 A |
| Solids passage [mm] | 11 x 5 | 6.2 |
| Height [mm] | 440 | 464 |
| Diameter [mm] | 185 | 188 |
| Weight [kg] | 14.5 | 13 |
