Product code 8119.280;
The Inox version of the sludge pumps will handle all kinds of sludges reliably thanks to the vortex recessed-impeller design. With its impressive allowed pH range, from 2 up to 11, it is hard to find an application that can’t be handled by the Inox pumps. The modular design drives service cost down. All materials in contact with the liquid are made out of AISI 316 stainless steel or better.
| Technical specifications Pump type: | Electrical submersible Three-phase |
| Classification: | IP 68 |
| Max submersion: | 20 meters |
| Cable: | 20 meters, SUBCAB: 3-phase: 4G2.5mm2 |
| Discharge connection: | Hose, ISO-G or NPT |
| Limitations: | ph 2-11 |
| Max liquid temp: | 40°C |
| Specifications | 50 HZ | 60 HZ |
| Discharge connection | 4″ | 4″ |
| Rated power P2 [KW] | 4.1 | 5.1 |
| Max. power consumption P1 [KW] | 5.2 | 6.2 |
| Shaft speed [r.p.m.] | 1350 | 1675 |
| Rated current at 230V | 15 A | 18 A |
| Rated current 2 | 8.8 A/400V | 9 A/460V |
| Rated current 3 | 7.7 A/500V | 7.3 A/570V |
| Solids passage [mm] | 80 | 80 |
| Height [mm] | 755 | 755 |
| Diameter [mm] | 480 | 480 |
| Weight [kg] | 86 | 86 |
