Product code 8123.281; The Solid pump excels in applications where reliability and easy handling are essential. Like its drainage equivalent, Mini, it is built to handle contaminated water, pH 5-8, and water containing relatively abrasive solids up to the size of 38 mm.
| Technical specifications Pump type: | Electrical submersible One-phase |
| Classification: | IP 68 |
| Max submersion: | 10 meters |
| Cable: | 10 m, H07RN-F, 3x1mm2, 16 m, SOW 16AWG/3 |
| Discharge connection: | Hose |
| Limitations: | pH 5-8,BSP or NPSM |
| Max liquid temp: | 40°C |
| Specifications | 50 HZ | 60 HZ |
| Discharge connection | 2″ | 2″ |
| Rated power P2 [W/KW] | 900 | 0.82 |
| Max. power consumption P1 [W/kW] | 120 | 1.1 |
| Shaft speed [r.p.m.] | 2800 | 3400 |
| Rated current at 115V | 11 A | 9.8 A |
| Rated current at 230V | 5.2 A | 4.8 A |
| Solids passage [mm] | 38 | 3.8 |
| Height [mm] | 510 | 510 |
| Width [mm] | 263 | 263 |
| Weight [kg] | 17 | 17 |
